    Setup: EdgeRouter 4 + co-lo + infrastructure

    IT Discussion
    edgerouter colocation it support
    4
    16
    906
    Loading More Posts
    • Oldest to Newest
    • Newest to Oldest
    • Most Votes
    Reply
    • Reply as topic
    Log in to reply
    This topic has been deleted. Only users with topic management privileges can see it.
    • FATeknollogeeF
      FATeknollogee
      last edited by

      • Have a co-lo space.
      • Have a block of 25 IP addresses.
      • Have 2x ER-4's.
      • Have a mix of servers (KVM, Hyper-V).
      • Have some vm's (voip, meshcentral etc) that will be public facing (not sure if that's the correct term).

      Questions:
      Thinking of splitting this into 2, with half the gear behind one ER-4 & the other half behind the second ER-4.
      Or just keep it real simple & use one ER-4.

      This is just a "thinking-out-loud", "gathering-your-thoughts" therapy session.

      Thoughts, feedback & critiquing are very much welcome...

      1 Reply Last reply Reply Quote 0
      • 1
        1337
        last edited by

        Can't edgerouter do
        failover?

        scottalanmillerS 1 Reply Last reply Reply Quote 0
        • scottalanmillerS
          scottalanmiller @1337
          last edited by

          @Pete-S said in Setup: EdgeRouter 4 + co-lo + infrastructure:

          Can't edgerouter do
          failover?

          As in a live/live cluster? That uses VRRP and yes, they can.

          https://help.ubnt.com/hc/en-us/articles/204962174-EdgeMAX-Virtual-Router-Redundancy-Protocol-VRRP-

          1 1 Reply Last reply Reply Quote 0
          • 1
            1337 @scottalanmiller
            last edited by

            @scottalanmiller said in Setup: EdgeRouter 4 + co-lo + infrastructure:

            @Pete-S said in Setup: EdgeRouter 4 + co-lo + infrastructure:

            Can't edgerouter do
            failover?

            As in a live/live cluster? That uses VRRP and yes, they can.

            https://help.ubnt.com/hc/en-us/articles/204962174-EdgeMAX-Virtual-Router-Redundancy-Protocol-VRRP-

            Then that is the way to go.

            scottalanmillerS 1 Reply Last reply Reply Quote 1
            • scottalanmillerS
              scottalanmiller @1337
              last edited by

              @Pete-S said in Setup: EdgeRouter 4 + co-lo + infrastructure:

              @scottalanmiller said in Setup: EdgeRouter 4 + co-lo + infrastructure:

              @Pete-S said in Setup: EdgeRouter 4 + co-lo + infrastructure:

              Can't edgerouter do
              failover?

              As in a live/live cluster? That uses VRRP and yes, they can.

              https://help.ubnt.com/hc/en-us/articles/204962174-EdgeMAX-Virtual-Router-Redundancy-Protocol-VRRP-

              Then that is the way to go.

              I would agree.

              JaredBuschJ 1 Reply Last reply Reply Quote 0
              • JaredBuschJ
                JaredBusch @scottalanmiller
                last edited by

                @scottalanmiller said in Setup: EdgeRouter 4 + co-lo + infrastructure:

                @Pete-S said in Setup: EdgeRouter 4 + co-lo + infrastructure:

                @scottalanmiller said in Setup: EdgeRouter 4 + co-lo + infrastructure:

                @Pete-S said in Setup: EdgeRouter 4 + co-lo + infrastructure:

                Can't edgerouter do
                failover?

                As in a live/live cluster? That uses VRRP and yes, they can.

                https://help.ubnt.com/hc/en-us/articles/204962174-EdgeMAX-Virtual-Router-Redundancy-Protocol-VRRP-

                Then that is the way to go.

                I would agree.

                It is the best thing to do. Sadly I have never had the leisure to actually test it. I have a pair of ERL in colo but they were put in place long before this feature was added.

                scottalanmillerS 1 Reply Last reply Reply Quote 1
                • FATeknollogeeF
                  FATeknollogee
                  last edited by

                  I'll add this to my list & test VRRP next week!

                  1 Reply Last reply Reply Quote 0
                  • FATeknollogeeF
                    FATeknollogee
                    last edited by

                    How about managing the IP's/port fwd etc between the router & the various vm's that are downstream?

                    1 1 Reply Last reply Reply Quote 0
                    • 1
                      1337 @FATeknollogee
                      last edited by 1337

                      @FATeknollogee said in Setup: EdgeRouter 4 + co-lo + infrastructure:

                      How about managing the IP's/port fwd etc between the router & the various vm's that are downstream?

                      Both firewalls have the same rules. You have a virtual IP, a VIP, and it belongs to the router in charge (master). If one router goes down the other one takes over the VIP.

                      Ideally there should also be state table synchronization between the routers. But it will probably work fine without it, just that clients needs to reestablish the link when you have a failure and the VIP moves to the other router.

                      1 Reply Last reply Reply Quote 0
                      • 1
                        1337
                        last edited by 1337

                        Out of your 25 IPs you will need one IP for each router and the rest are VIPs.

                        In a load sharing config you would have say 12 VIP normally belonging to router 1 and 11 VIPs normally belong to router 2.
                        If one router fails the other one takes over all VIPs.

                        1 Reply Last reply Reply Quote 0
                        • 1
                          1337
                          last edited by

                          On your LAN side each router would also have their own IP. And then minimum one VIP that would be the default gateway.

                          In load sharing config you would have two VIPs, each being the default gateway for their group of VMs.

                          FATeknollogeeF 1 Reply Last reply Reply Quote 1
                          • FATeknollogeeF
                            FATeknollogee @1337
                            last edited by

                            @Pete-S I'm more talking about how to manage the Public IPs being routed to the correct vm's for services like VOIP.

                            1 1 Reply Last reply Reply Quote 0
                            • 1
                              1337 @FATeknollogee
                              last edited by 1337

                              @FATeknollogee said in Setup: EdgeRouter 4 + co-lo + infrastructure:

                              @Pete-S I'm more talking about how to manage the Public IPs being routed to the correct vm's for services like VOIP.

                              As I said the firewalls have the same rules. The rules uses the VIPs. So you manage it the same as always.

                              PS. Read up a little on how VRRP works. Then it will be clearer. You will have lots of problems with configuring it all otherwise.

                              1 Reply Last reply Reply Quote 1
                              • scottalanmillerS
                                scottalanmiller @JaredBusch
                                last edited by

                                @JaredBusch said in Setup: EdgeRouter 4 + co-lo + infrastructure:

                                @scottalanmiller said in Setup: EdgeRouter 4 + co-lo + infrastructure:

                                @Pete-S said in Setup: EdgeRouter 4 + co-lo + infrastructure:

                                @scottalanmiller said in Setup: EdgeRouter 4 + co-lo + infrastructure:

                                @Pete-S said in Setup: EdgeRouter 4 + co-lo + infrastructure:

                                Can't edgerouter do
                                failover?

                                As in a live/live cluster? That uses VRRP and yes, they can.

                                https://help.ubnt.com/hc/en-us/articles/204962174-EdgeMAX-Virtual-Router-Redundancy-Protocol-VRRP-

                                Then that is the way to go.

                                I would agree.

                                It is the best thing to do. Sadly I have never had the leisure to actually test it. I have a pair of ERL in colo but they were put in place long before this feature was added.

                                Yeah, but I have been authorized to make some upgrades that will free up an ERL for us, and we have an ERL in our colo. So maybe I'll ship one out there to do this soon. That would be an awesome project.

                                JaredBuschJ 1 Reply Last reply Reply Quote 0
                                • JaredBuschJ
                                  JaredBusch @scottalanmiller
                                  last edited by

                                  @scottalanmiller said in Setup: EdgeRouter 4 + co-lo + infrastructure:

                                  @JaredBusch said in Setup: EdgeRouter 4 + co-lo + infrastructure:

                                  @scottalanmiller said in Setup: EdgeRouter 4 + co-lo + infrastructure:

                                  @Pete-S said in Setup: EdgeRouter 4 + co-lo + infrastructure:

                                  @scottalanmiller said in Setup: EdgeRouter 4 + co-lo + infrastructure:

                                  @Pete-S said in Setup: EdgeRouter 4 + co-lo + infrastructure:

                                  Can't edgerouter do
                                  failover?

                                  As in a live/live cluster? That uses VRRP and yes, they can.

                                  https://help.ubnt.com/hc/en-us/articles/204962174-EdgeMAX-Virtual-Router-Redundancy-Protocol-VRRP-

                                  Then that is the way to go.

                                  I would agree.

                                  It is the best thing to do. Sadly I have never had the leisure to actually test it. I have a pair of ERL in colo but they were put in place long before this feature was added.

                                  Yeah, but I have been authorized to make some upgrades that will free up an ERL for us, and we have an ERL in our colo. So maybe I'll ship one out there to do this soon. That would be an awesome project.

                                  Don't think I would try and live test in colo.

                                  scottalanmillerS 1 Reply Last reply Reply Quote 0
                                  • scottalanmillerS
                                    scottalanmiller @JaredBusch
                                    last edited by

                                    @JaredBusch said in Setup: EdgeRouter 4 + co-lo + infrastructure:

                                    @scottalanmiller said in Setup: EdgeRouter 4 + co-lo + infrastructure:

                                    @JaredBusch said in Setup: EdgeRouter 4 + co-lo + infrastructure:

                                    @scottalanmiller said in Setup: EdgeRouter 4 + co-lo + infrastructure:

                                    @Pete-S said in Setup: EdgeRouter 4 + co-lo + infrastructure:

                                    @scottalanmiller said in Setup: EdgeRouter 4 + co-lo + infrastructure:

                                    @Pete-S said in Setup: EdgeRouter 4 + co-lo + infrastructure:

                                    Can't edgerouter do
                                    failover?

                                    As in a live/live cluster? That uses VRRP and yes, they can.

                                    https://help.ubnt.com/hc/en-us/articles/204962174-EdgeMAX-Virtual-Router-Redundancy-Protocol-VRRP-

                                    Then that is the way to go.

                                    I would agree.

                                    It is the best thing to do. Sadly I have never had the leisure to actually test it. I have a pair of ERL in colo but they were put in place long before this feature was added.

                                    Yeah, but I have been authorized to make some upgrades that will free up an ERL for us, and we have an ERL in our colo. So maybe I'll ship one out there to do this soon. That would be an awesome project.

                                    Don't think I would try and live test in colo.

                                    http://www.quickmeme.com/img/08/085260da739d5f8723a626ab23a0da4623be9458998bfc91b38c57cdffec16d4.jpg

                                    1 Reply Last reply Reply Quote 0
